Customer Radiant System Install Photo Gallery

Explore real-world radiant heating installs from BlueRidge customers: slab-on-grade layouts, over-floor panels, staple-up between joists, and clean mechanical rooms with RHT pump panels and manifolds.

RHT Prefabricated Pump Distribution Panels

RHT Dominator Pump Panel, HTP Combi Boiler, SS-HF Manifold, Hydronic Fill/Purge Kit, and Tekmar Controls
RHT Dominator Pump Panel, HTP Combi Boiler, SS-HF Manifold, Hydronic Fill/Purge Kit, and Tekmar Controls
RHT 1-Zone Column Pump Panel, HTP Heat-only Boiler, SS-HF Manifold, Hydronic Fill/Purge Kit, and Tekmar Controls
RHT 1-Zone Column Pump Panel, HTP Heat-only Boiler, SS-HF Manifold, Hydronic Fill/Purge Kit, and Tekmar Controls
RHT 2-Zone Column Pump Panel, HTP Heat-only Boiler, Riifo Manifolds, Hydronic Fill/Purge Kit, Tekmar Controls, Axiom Neutralizer Pump
RHT 2-Zone Column Pump Panel, HTP Heat-only Boiler, Hydronic Fill/Purge Kit, Tekmar Controls, Axiom Neutralizer
RHT 1-Pump Matrix Electric Boiler Pump Panel, Thermolec 27 kW Boiler, Tekmar Switching Relay
RHT 1-Pump Matrix Electric Boiler Pump Panel, Thermolec 27 kW Boiler, Tekmar Switching Relay
RHT 3-Pump Dominator Panel with Dual Fuel Heat Exchanger module, and Heat-flo 60 Gal Indirect Tank
RHT 3-Pump Dominator Panel with Dual Fuel Heat Exchanger module, and Heat-flo 60 Gal Indirect Tank
RHT 4-Pump Dominator Panel, SpacePak 80 Gal Buffer tank, SS-HF Manifold, Heat-Pump Module, Tekmar Relays
RHT 4-Pump Dominator Panel, SpacePak 80 Gal Buffer tank, SS-HF Manifold, Heat-Pump Module, Tekmar Relays
RHT Dominator Pump Panel and SS-HF Manifold sub-zoned with actuators using Tekmar controllers
RHT Dominator Pump Panel with SS-HF Manifold sub-zoned via Tekmar controllers
RHT Dominator Pump Panel connected to a Laars Mascot FT boiler
RHT Dominator Pump Panel with Laars Mascot FT Boiler
RHT Column Pump Panel oriented off to the side of a Mascot FT boiler
RHT Column Pump Panel mounted in alternate orientation beside Mascot FT boiler
RHT Pump Panel with Thermolec Electric Boiler and wiring concealed behind panel
Thermolec Electric Boiler with RHT Pump Panel—wiring concealed behind panel
Electric boiler pump panel installed over a concrete slab
Electric Boiler Pump Panel over concrete slab
Large Thermolec electric boiler installed and running prior to concrete pour
Large Electric Boiler installed to run prior to pouring concrete

PEX Installations in Concrete

Creatherm S45 Radiant Insulation and PEX being installed in a 7200 sf Barndominium in Tennessee
Creatherm S45 Radiant Insulation and PEX being installed in a 7200 sf Barndominium in Tennessee
PEX tubing tied off to wire mesh and attached to RHT SS-HF Manifolds for pressure testing
PEX tubing tied off to wire mesh and attached to RHT SS-HF Manifolds for pressure testing
PEX tubing stapled down to Foam before a concrete pour
PEX tubing stapled down to Foam before a concrete pour
RHT Under Slab Insulation Panels installation prior to concrete pour
A nice installation using RHT Under Slab Insulation Panels
Creatherm insulation panels in a large pole barn prior to pour
A large pole barn using Creatherm Insulation Panels
Detail of Creatherm insulation panels in a large pole barn
Creatherm Insulation Panels – detail view
PEX stapled down to foam using the RHT PEX Foam Stapler before slab pour
PEX stapled down to foam using the RHT PEX Foam Stapler
An excellent installation of an SS-HF Manifold mid-slab
An excellent installation of an SS-HF Manifold mid-slab
Creatherm S45 R10 under slab insulation + SS-HF Manifold mid-slab being pressure tested
Creatherm S45 R10 under slab insulation + SS-HF Manifold mid-slab being pressure tested

RHT Floor Panel System - PEX Installed Over Subfloor

RHT Floor Panel System being laid out over subfloor
Laying out an RHT Floor Panel System
RHT Floor Panel sections before fastening heat transfer plates
Prior to fastening the RHT Heat Transfer Plates
Dog near RHT Floor Panel System install—fur-friend supervisor
An expert fur-friend radiant heating installer
RHT heat transfer plates fastened to the floor panel system
After fastening heat transfer plates
RHT SS-HF Manifold installed in a wall cavity behind access panel
RHT SS-HF Manifold installed in a wall cavity behind an access panel

Staple Up Between Joists - PEX Under Subfloor

Staple-up under subfloor with 24-inch Omega-style Heat Transfer Plates
Staple-up under subfloor with 24-inch Omega-style Heat Transfer Plates
RHT Maxima 6 inch extruded heat transfer plates installed between joists
Staple up using RHT Maxima 6" Extruded Heat Transfer Plates
Additional view of RHT Maxima extruded plates installed between joists
RHT Maxima 6" extruded plates – alternate view
